HV Diagnostics HVA68TD

HV Diagnostics HVA68TD is a VLF High Voltage Cable Test Set for medium voltage cables up to 46 kV per IEEE 400.2-2013. It performs VLF and DC testing, sheath testing with fault location mode, and integrates tan delta diagnostics, enabling longer cable runs or parallel phase testing with optional PC control.

Product Overview

• VLF and DC testing for medium voltage cables to 46 kV per IEEE 400.2-2013.
• Sheath testing with sheath fault location mode.
• Integrated tan delta diagnostics for condition assessment.
• Test longer runs or several phases in parallel; PC optional for use.

The HVA68TD VLF High Voltage Cable Test Set delivers VLF and DC testing for medium voltage cables to 46 kV, per IEEE 400.2-2013. It integrates sheath testing with fault location and tan delta diagnostics, supports longer runs or parallel phases, and operates with or without a PC in field environments.

Target Market

Ideal for utility distribution maintenance, industrial facilities, and electrical service contractors performing acceptance testing, troubleshooting insulation issues, sheath integrity checks, and condition assessment to IEEE 400.2-2013. Suits field environments requiring efficient VLF/DC testing of longer runs or multiple phases with integrated tan delta and sheath fault location capabilities.
